Opto Engineering SW07520

SW07520
$3,550.00Out Of Stock
  • 75 mm, 4/3 in. format (Ø 21 mm image circle)
  • Short Wave Infrared Lens
  • f/# 2
  • M.O.D. 750 mm
  • filter thread None
  • with Manual Focus and Locking Screws

To order, please request a quote and one of our representatives will provide you with delivery information.

Accessory Products

Description

SWIR series is a range of short-wave infrared lenses specifically designed to operate in the 0.9-1.7 µm wavelenght region. This serie has been specifically designed to match the new 15 µm format InGaAs FPA Focal Plane Arrays.
These lenses offer an industry standard C-mount threaded style interface or, alternatively, they can be equipped with a custom mount interface.

In the design of the lenses, great importance was attached to a good image quality and a large aperture (small F/#). These lenses, mounted on a SWIR camera, are the perfect choice for a variety of applications, including solar cell inspection, night vision imaging of outdoors scenes without additional illumination (security applications), detecting bruises on fruit, imaging through silicon, biomedical imaging and many other infrared applications.

Product Features:

  • 75 mm, 4/3 in. format (Ø 21 mm image circle)
  • Short Wave Infrared Lens
  • f/# 2
  • M.O.D. 750 mm
  • filter thread None
  • with Manual Focus and Locking Screws



Lens Mount:C-Mount
Format:4/3 in.
Focal Length:75 mm
Image Circle:21.00 mm
F#:2
M.O.D.:750 mm
Matching Pixels:15.00 µm
Spectral Range:900 to 1700 nm
Focus:Manual
Iris:None
Filter Size:None
Notes:SWIR Lens

Sample Images

  • Detection of bruises on fruit

    Detection of bruises on fruit

  • Interior of a car

    Interior of a car

  • Inspection of liquid levels

    Inspection of liquid levels

  • Inspection of liquid levels 2

    Inspection of liquid levels 2

  • Inspection of liquid levels 3

    Inspection of liquid levels 3
